Submersible sewage pump PCE-50-30-20-3
Price
General info
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Housing material | cast iron |
| Impeller | Cast iron |
| Shaft | Cast iron |
| Maximum Capacity, m3/h | 41 |
| Maximum head, m | 22 |
| Motor power, kW | 3 |
| Insulation class | F |
| Protection | ІР68 |
| Voltage, V | 400 |
| Frequency, Hz | 50 |
Submersible Sewage Pumping Unit PCE-50-30-20-3: Reliability for Complex Tasks
Ensure the continuous operation of your sewage system with the submersible sewage pumping unit PCE-50-30-20-3. This powerful and durable pump is specifically designed for the effective transfer of wastewater, including liquids with solid and fibrous inclusions. It is ideal for use in utility services, industry, and large facilities.
Key Advantages and Specifications
The PCE-50-30-20-3 pump is built for long-term operation in aggressive environments, offering exceptional performance and durability:
Maximum Flow Rate: 41 m³/h. High throughput for quick removal of large volumes of sewage.
Maximum Head: 22 m. Ensures the fluid can be lifted to a significant height, which is critical for deep collectors.
Motor Power: 3 kW. A powerful motor guarantees efficient operation even at peak loads.
Housing Material: Cast Iron. Exceptional strength and resistance to corrosion and mechanical damage.
Impeller: Cast Iron. A wear-resistant impeller effectively handles solid particles.
Shaft: Cast Iron. High corrosion resistance and reliability in contact with aggressive liquids.
Ingress Protection (IP): ІР68. Complete protection against dust and the ability to be continuously submerged in water under pressure.
Insulation Class: F. Allows for a high winding operating temperature, increasing motor reliability.
Voltage / Frequency: 400 V / 50 Hz. Three-phase connection, which is standard for industrial equipment.
Purpose and Application Area
Thanks to its technical parameters and reliable design, the PCE-50-30-20-3 pumping unit is the ideal choice for:
Pumping stations in municipal water and sewage utilities.
Treatment of industrial wastewater at manufacturing plants.
Dewatering flooded areas and premises.
Systems for pumping dirty and faecal water in the residential and public sector.
Choose the PCE-50-30-20-3 to get a powerful, durable, and reliable tool for managing the most challenging wastewater flows!
