Two-way inlet pump unit PD200-235(I)/2
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Type of pump unit | Two-way inlet pump unit |
| Appointment | pumping of large volumes of liquids of various consistencies, including pure water, technical water, liquids with a low content of impurities. Provides stable supply and uniform pressure for use at industrial facilities, in the water supply of cities, for various hydrotechnical structures, etc. |
| Voltage, V | 380 |
| Frequency, Hz | 50 |
| Max Head, m | 77 |
| Max Productivity, m3/h | 385 |
| Engine power, kW | 75 |
| Rotation speed, RPM | 2960 |
| Diameter of the impeller, mm | 235 |
| Pipe diameter, mm | DNs 200 DNd 150 |
| Case material | Cast Iron |
| Impeller material | Cast Iron |
PD200-235(I)/2 Double-Suction Pump Unit: Optimal Solution for High Loads
Introducing the PD200-235(I)/2 double-suction pump unit — a reliable and highly efficient device designed for pumping significant volumes of liquids with varying consistencies. This unit is ideally suited for handling clean water, technical water, and liquids with low impurity content, ensuring stable delivery and uniform pressure even in the most demanding conditions.
Key Features
- Reliable and Stable Operation: Ensures uninterrupted liquid supply and uniform pressure, which is critically important for the optimal functioning of any system.
- High Capacity: Designed for pumping large volumes of liquids, enabling the tackling of large-scale tasks.
- Durability and Resistance: The casing and impeller are made from cast iron, guaranteeing exceptional reliability, durability, and wear resistance under intensive use.
- Convenient Connection: The double-suction inlet and optimal nozzle diameters (200 mm suction, 150 mm discharge) simplify installation and integration into existing systems.
Areas of Application
The PD200-235(I)/2 pump unit is an ideal choice for:
- Industrial Facilities: Providing for production processes, cooling systems, and other technological needs.
- Urban Water Supply: Reliable operation of water supply and wastewater systems.
- Hydraulic Structures: Effective performance in dams, irrigation systems, and other hydraulic engineering projects.
- Any other areas requiring stable pumping of large volumes of liquids with various consistencies.
Technical Specifications
- Pump Unit Type: Double-Suction Pump Unit
- Voltage: 380 V
- Frequency: 50 Hz
- Rotational Speed: 2960 rpm
- Impeller Diameter: 235 mm
- Suction Nozzle Diameter: 200 mm
- Discharge Nozzle Diameter: 150 mm
- Casing Material: Cast Iron
- Impeller Material: Cast Iron
Choose the PD200-235(I)/2 for your project to ensure the uninterrupted and efficient operation of your liquid pumping system.
Replace your old D320-50 pump with the modern PD200-235(I)/2: the investment pays back in just one year through electricity savings, bringing continuous profit thereafter.
Contact us for a detailed consultation or to place an order!
