Two-way inlet pump unit PD125-280(I)/2
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Type of pump unit | Two-way inlet pump unit |
| Appointment | pumping of large volumes of liquids of various consistencies, including pure water, technical water, liquids with a low content of impurities. Provides stable supply and uniform pressure for use at industrial facilities, in the water supply of cities, for various hydrotechnical structures, etc. |
| Voltage, V | 380 |
| Frequency, Hz | 50 |
| Max Head, m | 110 |
| Max Productivity, m3/h | 245 |
| Engine power, kW | 90 |
| Rotation speed, RPM | 2960 |
| Diameter of the impeller, mm | 280 |
| Pipe diameter, mm | DNs 125 DNd 80 |
| Case material | Cast Iron |
| Impeller material | Stainless Steel |
PD125-280(I)/2 Double Suction Pump Unit: Exceptional Performance for Large-Scale Systems
Introducing the PD125-280(I)/2 double suction pump unit — a powerful and reliable solution designed for pumping significant volumes of liquids of various consistencies. This unit is ideally suited for handling clean water, technical water, and liquids with a low impurity content, ensuring stable flow and uniform pressure even under the most demanding conditions.
Key Features and Benefits
- High Performance: The unit can pump up to 245 m³/h of liquid with a head of up to 110 meters, making it indispensable for large-scale projects.
- Stable Operation: Thanks to its rotational speed of 2960 rpm and an impeller diameter of 280 mm, the pump guarantees uninterrupted delivery and uniform pressure without interruptions.
- Reliability and Durability: The casing and impeller, made from cast iron, provide high corrosion resistance and significantly extend the equipment's service life.
- Versatility: Designed for pumping a wide range of liquids, including clean and technical water, as well as liquids with minor impurities.
Areas of Application
The PD125-280(I)/2 pump unit is an ideal choice for the following industries:
- Industrial Facilities: Providing water for production processes, cooling systems, and other technological needs.
- Urban Water Supply: Efficient and reliable water pumping for municipal utility systems.
- Hydraulic Structures: Use in irrigation systems, drainage, dams, locks, and other hydraulic engineering facilities.
- Any projects requiring stable and high-performance liquid delivery under pressure.
Technical Specifications
- Pump Unit Type: Double-Suction Pump Unit
- Voltage: 380 V
- Frequency: 50 Hz
- Head: 110 m
- Capacity: 245 m³/h
- Rotational Speed: 2960 rpm
- Impeller Diameter: 280 mm
- Nozzle Diameter: DNs 250 mm (inlet); DNd 200 mm (outlet)
- Casing Material: Stainless Steel
- Impeller Material: Stainless Steel
Choose the PD125-280(I)/2 for your project to ensure the uninterrupted and efficient operation of your liquid pumping system.
Replace your old 1D 200-90 pump with the modern PD125-280(I)/2: investment payback from one year due to electricity savings, and then only profit..
Contact us for a more detailed consultation or to place an order!
