Циркуляційний насос EKV-CPFM-50/40
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Housing material | cast iron cataphoresis coating |
| Impeller | PES GF 30 |
| Shaft | AISI 420 stainless steel |
| Bearings | all carbon |
| Maximum Capacity, m3/h | 24.17 |
| Head, м | 4.29 |
| Power input max, W | 160 |
| Pressure flange diameter | 50 |
| Montage dovzhina, m | 280 |
| Installation | Flange connection |
| Insulation class | Н |
| Protection | ІР44 |
| Voltage, V | 230 |
Highly efficient circulation pump EKV-CPFM-50/40: The optimal choice for heating, air conditioning, closed cooling circuits and industrial applications.
Electronic control and wet rotor: Ensures reliable and quiet operation.
VDI 2035 compliance: Designed for systems operating in accordance with this standard.
Energy-efficient ECM technology: Reduces energy consumption with a permanent magnet motor.
User-friendly operation: Easy-to-use LED display.
Built-in surge protection: Increases safety and durability.
Easy installation and quiet operation: Simplifies installation and ensures comfort.
Automatic air venting: Maintains system efficiency.
Automatic and night mode: Allows you to optimize energy consumption.
Robust and compact design: Guarantees a long service life.
Integrated thermal insulation: Reduces heat loss.
Upgradeable communication modules: Ensures flexibility and future compatibility.
Operating modes:
- Automatic mode
- Proportional pressure
- Constant pressure
- Fixed speed
- Night mode
Safety features:
- Dry run protection
- Automatic ventilation
High energy efficiency: EEI class ≤ 0.2.
Compatible liquids: Pure water or water-glycol solutions (glycol content > 20%).
Liquid temperature range: -10 °C to +110 °C.
Installation length: 280 mm
Maximum ambient temperature: 40 °C.
