Cantilever monobloc pump unit PKM65-160
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Type of pump unit | Console monoblock |
| Appointment | They are designed for pumping clean (cold/hot) water in water supply systems of housing and communal services, municipal water utilities, in industrial water supply systems, to ensure technological processes of industrial enterprises, including oil refining and metallurgical industries |
| Voltage, V | 380 |
| Frequency, Hz | 50 |
| Max Head, m | 12,5 |
| Max Productivity, m3/h | 25 |
| Engine power, kW | 4 |
| Rotation speed, RPM | 2960 |
| Diameter of the impeller, mm | 160 |
| Pipe diameter, mm | 65 |
| Case material | cast iron |
| Impeller material | cast iron |
| Weight, Kg | 8 |
PKM65-160 Cantilever Monoblock Pump: Efficiency and Reliability
The PKM65-160 cantilever monoblock pump is a versatile and reliable solution for pumping water and other liquids with properties similar to water. It's ideally suited for various industries, ensuring stable flow without solid particles.
Key Advantages:
Wide Range of Applications: Designed for pumping clean cold and hot water in communal services water supply systems, municipal water utilities, technical water supply systems, and for technological processes in industrial enterprises (oil refining, metallurgical industries).
High Performance and Head: Provides a maximum head of up to 12.5 m and a flow rate of up to 25 m³/h.
Reliability: Made from high-quality cast iron (casing and impeller), ensuring a long service life.
Optimal Characteristics: A 4 kW motor with a speed of 2960 rpm delivers high efficiency.
Compactness: Occupies less space, simplifying installation and integration.
Technical Specifications:
Voltage: 380 V
Frequency: 50 Hz
Maximum Head: 12.5 m
Maximum Flow Rate: 25 m³/h
Motor Power: 4 kW
Rotation Speed: 2960 rpm
Impeller Diameter: 160 mm
Nozzle Diameter: 65 mm
Casing Material: Cast Iron
Impeller Material: Cast Iron
Weight: 8 kg
Choose the PKM65-160 for your project to ensure uninterrupted and efficient liquid pumping system operation. Replace your old KM65-50-160 pump with the modern PKM65-160: the investment pays for itself from one year thanks to energy savings, and then it's pure profit.
