АИР63B2 electric motor 0,55 KW 3000 rpm ІМ1081
Price
General info
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Electric Motor type | general industrial |
| Power, kW | 0,55 |
| Phase | 3 |
| Voltage, V | 220/380 |
| Number of poles | 2 |
| Shaft diameter, mm | 14 |
| Rotation speed, rpm | 3000 |
| Mounting version | ІМ1081, ІМ2081, ІМ3081, ІМ2181, ІМ3181 |
| Power factor | 0,82 |
| Climatic version | U2 |
| Protection class | IP55 |
| Ratio max. force torque to nominal | 2,3 |
| Ratio of starting current to rated current | 5,7 |
| Ratio of starting torque to nominal | 2,2 |
| Current frequency, Hz | 50 |
| Efficiency, % | 72,7 |
| Weight, Kg | 6,4 |
| Country of origin | Ukraine |
Description
AIR63V2 0.55 kW 3000 rpm IM1081 electric motor is a general-purpose electric motor that has low noise characteristics and high efficiency. Due to its technical parameters and reliable performance, this electric motor is an ideal solution for various industrial applications.
Features
- Voltage: 220/380 V
- Efficiency: 72.7%
- Phase: 3
- Number of poles: 2
- Shaft diameter: 14 mm
- Speed: 3000 rpm
- Mounting design: IM1081, IM2081, IM3081, IM2181, IM3181
- Power factor: 0.82
- Protection class: IP55
- Climatic design: U2
- Ratio of maximum torque, force to nominal: 2.3
- Ratio of starting current to nominal: 5.7
- Ratio of starting torque, force to nominal: 2.2
- Current frequency: 50 Hz
- Weight: 6.4 kg
- Country of origin: Ukraine
Power: 0.55 kW
Usage
This electric motor can be used in various industrial sectors, including machinery, food industry, petrochemical industry, textile industry, and many other fields. It is ideal for driving pump units, compressors, conveyors, milling machines, and other mechanisms that require a reliable and powerful electric motor.
Technical Specifications
- Power, kW: 0.55
- Voltage, V: 220/380
- Efficiency, %: 72.7
- Phase: 3
- Number of poles: 2
- Shaft diameter, mm: 14
- Speed, rpm: 3000
- Mounting design: IM1081, IM2081, IM3081, IM2181, IM3181
- Power factor: 0.82
- Protection class: IP55
- Climatic design: U2
- Ratio of maximum torque, force to nominal: 2.3
- Ratio of starting current to nominal: 5.7
- Ratio of starting torque, force to nominal: 2.2
- Current frequency, Hz: 50
- Weight, kg: 6.4
- Country of origin: Ukraine
Type of electric motor: general-purpose
