АИР56B2 electric motor 0,25 KW 3000 rpm ІМ1081
In Stock
Price
1 836.00 ₴
2 350.00 ₴
General info
2 years warranty
Оn electric motors and pump units.
The warranty on generators is from 1 year.
Fast shipping
In any way convenient for you
25 years of experience
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Electric Motor type | general industrial |
| Power, kW | 0,25 |
| Phase | 3 |
| Voltage, V | 220/380 |
| Number of poles | 2 |
| Shaft diameter, mm | 11 |
| Rotation speed, rpm | 3000 |
| Mounting version | ІМ1081, ІМ2081, ІМ3081, ІМ2181, ІМ3181 |
| Power factor | 0,78 |
| Climatic version | U2 |
| Protection class | IP55 |
| Ratio max. force torque to nominal | 2,2 |
| Ratio of starting current to rated current | 5,3 |
| Ratio of starting torque to nominal | 2,2 |
| Current frequency, Hz | 50 |
| Efficiency, % | 68 |
| Weight, Kg | 5,1 |
| Country of origin | Ukraine |
Description
AIR56V2 is a general-purpose type of electric motor with a power of 0.25 kW and a speed of 3000 rpm.
Features
- Voltage: 220/380 V
- Efficiency: 68%
- Phase: 3
- Number of poles: 2
- Shaft diameter: 11 mm
- Rotation speed: 3000 rpm
- Mounting design: IM1081, IM2081, IM3081, IM2181, IM3181
- Power factor: 0.78
- Protection class: IP55
- Climatic design: U2
- Ratio of maximum torque, force to nominal: 2.2
- Ratio of starting current to nominal: 5.3
- Ratio of starting torque, force to nominal: 2.2
- Current frequency: 50 Hz
- Weight: 5.1 kg
- Country of origin: Ukraine
Power: 0.25 kW
Usage
The AIR56V2 electric motor is ideal for use in various industrial sectors where reliable and efficient operation of electric mechanisms is required. Thanks to its power and high quality of manufacturing, this electric motor ensures stable functioning and a long service life.
Technical Specifications
- Power, kW: 0.25
- Voltage, V: 220/380
- Efficiency, %: 68
- Phase: 3
- Number of poles: 2
- Shaft diameter, mm: 11
- Rotation speed, rpm: 3000
- Mounting design: IM1081, IM2081, IM3081, IM2181, IM3181
- Power factor: 0.78
- Protection class: IP55
- Climatic design: U2
- Ratio of maximum torque, force to nominal: 2.2
- Ratio of starting current to nominal: 5.3
- Ratio of starting torque, force to nominal: 2.2
- Current frequency, Hz: 50
- Weight, kg: 5.1
- Country of origin: Ukraine
Type of motor: general-purpose
