АИР250S8 electric motor 37 KW 750 rpm IM1081
Price
General info
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Electric Motor type | general industrial |
| Power, kW | 37 |
| Phase | 3 |
| Voltage, V | 380/660 |
| Number of poles | 8 |
| Shaft diameter, mm | 75 |
| Rotation speed, rpm | 750 |
| Mounting version | ІМ1081, ІМ2081, ІМ3081 |
| Power factor | 0,79 |
| Climatic version | U2 |
| Protection class | IP55 |
| Ratio max. force torque to nominal | 2,3 |
| Ratio of starting current to rated current | 6,2 |
| Ratio of starting torque to nominal | 2,1 |
| Current frequency, Hz | 50 |
| Efficiency, % | 90,5 |
| Weight, Kg | 465 |
| Country of origin | Ukraine |
Description
AIR250S8 is a general-purpose industrial motor with a power of 37 kW and a speed of 750 rpm. It has a high efficiency coefficient of 90.5%, which ensures efficient operation and energy savings. This motor has 3 phases and 8 poles, making it an ideal choice for a wide range of applications.
Features
- Shaft diameter: 75 mm
- Protection class: IP55
- Climatic design: U2
- Weight: 465 kg
- Country of origin: Ukraine
Mounting design: IM1081, IM2081, IM3081
Usage
The AIR250S8 motor with a power of 37 kW and 750 rpm is used in various industrial sectors to drive mechanisms, machines, and equipment. Its high efficiency coefficient ensures efficient operation and reduces electricity costs. This motor is a reliable and durable solution for any production.
Technical Specifications
- Power: 37 kW
- Voltage: 380/660 V
- Efficiency: 90.5%
- Phase: 3
- Number of poles: 8
- Shaft diameter: 75 mm
- Speed: 750 rpm
- Mounting design: IM1081, IM2081, IM3081
- Power factor: 0.79
- Protection class: IP55
- Climatic design: U2
- Max. torque to nominal force ratio: 2.3
- Starting current to nominal current ratio: 6.2
- Starting torque to nominal force ratio: 2.1
- Current frequency: 50 Hz
- Weight: 465 kg
- Country of origin: Ukraine
Motor type: general-purpose
