АИММ132M8 explosion-proof electric motor 5.5 kW 750 rpm ІМ1081
Price
General info
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Electric Motor type | explosion-proof |
| Power, kW | 5.5 |
| Voltage, V | 220/380, 380/660 |
| Number of poles | 8 |
| Rotation speed, rpm | 750 |
| Mounting version | ІМ1081, ІМ2081, ІМ3081 |
| Power factor | 0.74 |
| Іnsulation class | F |
| Climatic version | УХ/1, УХЛ2, У1, У2, У3, У5 |
| Explosion protection | 1ExdIIBT4 |
| Protection class | IP54 |
| Ratio max. force torque to nominal | 1.9 |
| Ratio of starting current to rated current | 6 |
| Ratio of starting torque to nominal | 2 |
| Current frequency, Hz | 50 |
| Efficiency, % | 83 |
| Weight, Kg | 91 |
| Country of origin | Ukraine |
Description
AИMM132M8 is an explosion-proof electric motor with a power of 5.5 kW and a voltage of 220/380, 380/660 V. This electric motor has a high efficiency coefficient of 83% and consists of 8 poles. It operates at a speed of 750 rpm and has mounting options IM1081, IM2081, IM3081. This electric motor is characterized by high quality, reliability, and complies with all safety standards.
Features
- Has a high efficiency coefficient - 83%
- Designed with 8 poles for efficient operation
- Mounting options IM1081, IM2081, IM3081
- Offers reliability and long service life
Explosion-proof electric motor with a power of 5.5 kW
Usage
The AИMM132M8 electric motor is widely used in various industrial sectors. It can be used in the oil, gas, and chemical industries where explosion protection is required. This electric motor can be used for driving pumps, fans, compressors, and other equipment used in hazardous conditions.
Technical Specifications
- Power, kW: 5.5
- Voltage, V: 220/380, 380/660
- Efficiency, %: 83
- Number of poles: 8
- Speed, rpm: 750
- Mounting options: IM1081, IM2081, IM3081
- Power factor: 0.74
- Protection class: IP55
- Climatic execution: UH/1, UHL2, U1, U2, U3, U5
- Ratio of maximum torque to nominal force: 1.9
- Ratio of starting current to nominal: 6
- Ratio of starting torque to nominal force: 2
- Current frequency, Hz: 50
- Weight, kg: 91
- Country of origin: Ukraine
- Insulation class: F
- Explosion protection execution: II 2G Ex db IIB T4 Gb
Motor Type: Explosion-proof
