АИММ 112M4 explosion-proof electric motor 5.5 kW 1500 rpm ІМ1081
Price
General info
Оn electric motors and pump units.
The warranty on generators is from 1 year.
In any way convenient for you
They provide a comprehensive solution to the energy generation, engineering and driving force needs of your enterprise.
Characteristics
| Electric Motor type | explosion-proof |
| Power, kW | 5.5 |
| Voltage, V | 220/380, 380/660 |
| Number of poles | 4 |
| Rotation speed, rpm | 1500 |
| Mounting version | ІМ1081, ІМ2081, ІМ3081 |
| Power factor | 0.83 |
| Іnsulation class | F |
| Climatic version | УХ/1, УХЛ2, У1, У2, У3, У5 |
| Explosion protection | 1ExdIIBT4 |
| Protection class | IP54 |
| Ratio max. force torque to nominal | 2.3 |
| Ratio of starting current to rated current | 7 |
| Ratio of starting torque to nominal | 2.3 |
| Current frequency, Hz | 50 |
| Efficiency, % | 85.7 |
| Weight, Kg | 67.5 |
| Country of origin | Ukraine |
Product Description:
AИMM 112M4 is an explosion-proof electric motor that offers a power of 5.5 kW and a speed of 1500 rpm. This electric motor ensures reliable and efficient operation in hazardous explosive environments.
Features:
- IP54 protection class, providing protection against moisture and dust
- Insulation class F for safe use
- Mounting design: IM1081, IM2081, IM3081, providing flexibility in choosing the mounting location
- Explosion protection execution 1ExdIIBT4 for work safety in explosive environments
Explosion-proof electric motor with high power and reliable operation
Usage:
AИMM 112M4 explosion-proof electric motor is necessary for use in industries where safe operation with electric motors in explosive zones is required. These can be oil and gas industries, chemical plants, and various other conditions where explosive substances are present.
Technical Specifications:
- Power, kW: 5.5
- Voltage, V: 220/380, 380/660
- Efficiency, %: 85.7
- Number of poles: 4
- Speed, rpm: 1500
- Mounting design: IM1081, IM2081, IM3081
- Power factor: 0.83
- Protection class: IP54
- Climatic design: UX/1, UXL2, U1, U2, U3, U5
- Max. torque to nominal force ratio: 2.3
- Starting current to nominal current ratio: 7
- Starting torque to nominal force ratio: 2.3
- Current frequency, Hz: 50
- Weight, kg: 67.5
- Country of origin: Ukraine
- Insulation class: F
- Explosion protection execution: 1ExdIIBT4
Motor type: explosion-proof
